| Model Version | FS105D 3.0 |
|---|
| Interfaces | 10/100 Mbps RJ45 Ports | 5 |
|---|
| LED | - Power
- Link/ACT of Each Ethernet Port
|
|---|
| Power Input | DC Jack |
|---|
| Performance | Copper Speed and Distance | - Cat. 3 or higher cable: 100 meters at 10 Mbps
- Cat. 5 or higher cable: 100 meters at 100 Mbps
|
|---|
| MAC Address Table | 512 |
|---|
| Max Switching Capacity | 1 Gbps |
|---|
| Max Forwarding Rate | 0.744 Mpps |
|---|
| Packet Buffer | 448 Kbit |
|---|
| Power | Basic Power Saving | True |
|---|
| Power Methods | DC |
|---|
| DC | 5V?0.55A |
|---|
| Power Adapter | Input: 100-240V~, 50/60Hz
Output: 5V?0.55A |
|---|
| Max Power Consumption | 0.9W |
|---|
| Idle Power Consumption | 0.25W |
|---|
| Switching | 802.3 Protocols | - 802.3i 10BASE-T
- 802.3u 100BASE-TX
|
|---|
| Reliability | Environment | Operating Temperature: 0 ? ~ 40 ? (32 ? ~104 ?)
Storage Temperature: -40 ? ~ 70 ? (-40 ? ~ 158 ?)
Operating Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5% ~ 90% non-condensing |
|---|
| Mechanical | Dimension | 88×52.5×24 mm
3.46×2.07×0.94 inches |
|---|
| Product Weight | 50 g (1.76 oz.) |
|---|
| Casing Material | Plastic |
|---|
| Installation | |
|---|
| Package Content | - FS105D
- Power Adapter
- Installation Guide
|
|---|
| Ordering Information | Retail Package Dimension | - EU/US:
92×88×57 mm
3.62×3.46×2.24 inches - UK:
92×88×78 mm
3.62×3.46×3.07 inches
|
|---|
| Retail Package Weight | - EU: 132 g (4.66 oz.)
- UK: 166 g (5.86 oz.)
- US: 139 g (4.9 oz.)
|
|---|
| Units per Carton | |
|---|
| Carton Net Weight | - EU: 13.2 kg (29.1 lbs)
- UK: 16.4 kg (36.16 lbs)
- US: 13.9 kg (30.64 lbs)
|
|---|
| Carton Gross Weight | - EU: 14.1 kg (31.09 lbs)
- UK: 17.5 kg (38.58 lbs)
- US: 14.7 kg (32.41 lbs)
|
|---|
| Carton Dimension | - EU/US: 48.7×31.2×38.5 cm
19.17×12.28×15.16 inches - UK: 48.3×41.8×37.9 cm
19.02×16.46×14.92 inches
|
|---|
