| Model Version | FS106P 1.0 |
|---|
| Interfaces | 10/100 Mbps RJ45 Ports | 6 |
|---|
| 10/100 Mbps RJ45 PoE Ports | #1~#4 |
|---|
| Max Power on a Single PoE Port | 30W |
|---|
| PoE Port Notes | The PoE ports comply with IEEE 802.3at/af standards. |
|---|
| PoE Priority | Intelligent Power Management:
Automatically disconnect the lastly powered device when power exceeds budget. |
|---|
| Extend Mode Ports | #1~#4 |
|---|
| VLAN Mode Ports | #1~#4 |
|---|
| LED | - Power
- Link/ACT of Each Ethernet Port
- Extend Status
- VLAN Status
|
|---|
| Power Input | DC Jack |
|---|
| Physical Buttons | VLAN/Default/Extend DIP Switch |
|---|
| Physical Buttons Note | The PoE Watchdog is on under the VLAN/Extend modes and will attempt to reboot the plugged-in but inactive client. |
|---|
| Performance | Copper Speed and Distance | - Cat. 3 or higher cable: 100 meters at 10 Mbps
- Cat. 5 or higher cable: 100 meters at 100 Mbps
- Cat. 5e or higher cable: 250 meters at 10 Mbps
|
|---|
| Copper Speed and Distance Note | 250-meter transmission is only available on the Extend Mode ports when the Extend Mode is activated. |
|---|
| MAC Address Table | 2048 |
|---|
| Max Switching Capacity | 1.2 Gbps |
|---|
| Max Forwarding Rate | 0.8928 Mpps |
|---|
| Jumbo Frame | 2 KB |
|---|
| Packet Buffer | 570 Kbit |
|---|
| Power | Power Methods | DC |
|---|
| DC | 54V?0.66A |
|---|
| Power Adapter | Input: 100-240V~, 50/60Hz
Output: 54V?0.93A |
|---|
| Power Supply | 36W |
|---|
| Max Power Excluding PoE | 2W |
|---|
| Switching | 802.3 Protocols | - 802.3i 10BASE-T
- 802.3u 100BASE-TX
- 802.3x Flow Control
- 802.3af PoE
- 802.3at PoE
|
|---|
| Reliability | EMS | IEC/EN 61000-4-2, Level 3 ESD: Contact: 6kV; Air: 8kV
IEC/EN 61000-4-5, Level 4 Surge: Power: DM 2kV, CM 4kV; RJ45: CM 4kV |
|---|
| Environment | Operating Temperature: 0~40 ? (32~104 ?)
Storage Temperature: -40~70? (-40~158 ?)
Operating Humidity: 10~90% non-condensing
Storage Humidity: 10~95% non-condensing |
|---|
| Mechanical | Dimension | 138×61.5×24 mm
5.43×2.42×0.94 inches |
|---|
| Product Weight | 88.0 g (3.1 oz.) |
|---|
| Casing Material | Plastic |
|---|
| Installation | |
|---|
| Package Content | - FS106P
- Power Adapter
- Power Cord
- Installation Guide
|
|---|
| Ordering Information | Retail Package Dimension | 151×95×72 mm
5.94×3.74×2.83 inches |
|---|
| Retail Package Weight | EU: 367.7 g (12.97 oz.) |
|---|
| Units per Carton | 30 |
|---|
| Carton Net Weight | EU: 11.0 kg (24.25 lbs) |
|---|
| Carton Gross Weight | EU: 11.8 kg (26.01 lbs) |
|---|
| Carton Dimension | 48×38×21.2 cm
18.9×14.96×8.35 inches |
|---|
