| Model Version | AP1300 1.0 |
|---|
| CPU | CPU Details | 880 MHz Dual-Core CPU |
|---|
| Memory/Storage | Flash/ROM | 16 MB (128 Mbit) NOR |
|---|
| DDR/RAM | 128 MB (1 Gbit) DDR3 |
|---|
| Wireless | 5 GHz Wi-Fi Speed | 867 Mbps |
|---|
| 2.4 GHz Wi-Fi Speed | 300 Mbps |
|---|
| 5 GHz Wi-Fi Streams | 2T2R (2×2 MIMO) |
|---|
| 2.4 GHz Wi-Fi Streams | 2T2R (2×2 MIMO) |
|---|
| Wi-Fi Antennas | 4× Internal |
|---|
| FEM or PA/LNA | - 5 GHz: 2× Internal
- 2.4 GHz: 2× Internal
|
|---|
| Beamforming | True |
|---|
| Range Performance | Max: 170 m (558 ft)
Tested in open-space environments with minimal interference. Actual WiFi range may vary depending on layout and wall materials. Refer to the Wall Performance specifications for placement suggestions. |
|---|
| Wall Performance | Two wooden walls with thickness < 10 cm (4'')
One concrete wall with thickness < 20 cm (7'') |
|---|
| Interfaces | Gigabit RJ45 Ports | 1 |
|---|
| Ethernet Notes | Accepts PoE powering |
|---|
| LED | System |
|---|
| Physical Buttons | Reset Button |
|---|
| Power Input | - DC Jack
- PoE via Ethernet Port
|
|---|
| Power | Power Methods | - DC
- Passive PoE
- 802.3at/af PoE
|
|---|
| DC Input | 12V 1A |
|---|
| Passive PoE Input | 24 ~ 57V |
|---|
| Power Adapter | AP1300 | DC Adapter in the box:
Input: 100 ~ 240 V, 50/60 Hz AC
Output: 12V 1A DC
AP1300_P | PoE Adapter in the box:
Input: 100 ~ 240 V, 50/60 Hz AC
Output: 48V Passive PoE |
|---|
| Max Power Consumption (W) | Max (PoE): 11 W
Max (DC): 7.5 W |
|---|
| Idle Power Consumption (W) | 4.008 W |
|---|
| Reliability | Advanced | Hardware Watchdog |
|---|
| EMC | ESD: Contact: 4kV; Air: 8kV |
|---|
| Environment | Operating Temperature: -10 ? ~ 65 ? (14 ? ~149 ?)
Storage Temperature: -40 ? ~ 70 ? (-40 ? ~ 158 ?)
Operating Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5% ~ 90% non-condensing |
|---|
| Certifications | FCC, CE |
|---|
| Mechanical | Installation | |
|---|
| Dimension | F231.9×57.1 mm
F9.13×2.25 inches |
|---|
| Product Weight | 400 g (14.11 oz.) |
|---|
| Package Content | - AP1300
- Power Adapter
- Mounting Kit
- Ethernet Cable
- Installation Guide
|
|---|
| Ordering Information | Retail Package Weight | - With DC Adapter | EU: 817 g (28.82 oz.)
- With PoE Adapter (_P) | EU: 920 g (32.45 oz.)
- With DC Adapter | US: 809 g (28.54 oz.)
|
|---|
| Retail Package Dimension | 283×238×68 mm
11.14×9.37×2.68 inches |
|---|
| Units per Carton | 20 |
|---|
| Carton Net Weight | - With DC Adapter | EU: 16.3 kg (35.94 lbs)
- With PoE Adapter (_P) | EU: 18.4 kg (40.57 lbs)
- With DC Adapter | US: 16.2 kg (35.71 lbs)
|
|---|
| Carton Gross Weight | - With DC Adapter | EU: 17.7 kg (39.02 lbs)
- With PoE Adapter (_P) | EU: 19.8 kg (43.65 lbs)
- With DC Adapter | US: 18.6 kg (41.01 lbs)
|
|---|
| Carton Dimension | 58×37.5×49.5 cm
22.83×14.76×19.49 inches |
|---|
