| Model Version | GP1200 1.0 |
|---|
| CPU | CPU Details | 1.15 GHz Dual-Core |
|---|
| Memory/Storage | Flash/ROM | 128 MB (1 Gbit) NAND |
|---|
| DDR/RAM | 256 MB (2 Gbit) DDR3 |
|---|
| xPON | Protocols | - GPON (ITU G. 984 standard | Class B+)
- EPON (802.3ah)
|
|---|
| Speed | - GPON: 2.488 Gbps Downstream / 1.244 Gbps Upstream
- EPON: 1.25 Gbps Downstream / Upstream
|
|---|
| Wavelength | TX: 1310 nm
RX: 1490 nm |
|---|
| Max Transmission Distance | 20 km |
|---|
| Wireless | 5 GHz Wi-Fi Speed | 867 Mbps |
|---|
| 2.4 GHz Wi-Fi Speed | 300 Mbps |
|---|
| 5 GHz Wi-Fi Streams | 2T2R (2×2 MIMO) |
|---|
| 2.4 GHz Wi-Fi Streams | 2T2R (2×2 MIMO) |
|---|
| Wi-Fi Antennas | 2× Fixed |
|---|
| FEM or PA/LNA | - 5 GHz: 2× Internal
- 2.4 GHz: 2× Internal
|
|---|
| Beamforming | True |
|---|
| Range Performance | Max: 170 m (558 ft)
Tested in open-space environments with minimal interference. Actual WiFi range may vary depending on layout and wall materials. Refer to the Wall Performance specifications for placement suggestions. |
|---|
| Wall Performance | Two wooden walls with thickness < 10 cm (4'')
One concrete wall with thickness < 20 cm (7'') |
|---|
| Interfaces | SC/APC Port | 1 |
|---|
| Gigabit RJ45 Ports | 4 |
|---|
| Ethernet Notes | 1× LAN/WAN port, the rest are LAN ports. |
|---|
| USB-A 2.0 Ports | Optional for ISP Order |
|---|
| LED | - Power
- PON
- LOS
- Internet
- 2.4 GHz Wi-Fi
- 5 GHz Wi-Fi
- WPS
- LAN
|
|---|
| Physical Buttons | - Power On/Off Button
- Reset Button
- WPS Button
- Wi-Fi On/Off Button
|
|---|
| Power Input | DC Jack |
|---|
| Power | Power Methods | DC |
|---|
| DC Input | 12V 1A |
|---|
| Power Adapter | Input: 100-240V~, 50/60 Hz
Output: 12V?1A |
|---|
| Reliability | Environment | Operating Temperature: 0 ? ~ 40 ? (32 ? ~104 ?)
Storage Temperature: -40 ? ~ 70 ? (-40 ? ~ 158 ?)
Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5% ~ 95% non-condensing |
|---|
| Certifications | FCC, CE |
|---|
| Mechanical | Installation | |
|---|
| Dimension | 173×123.8×33 mm
6.81×4.87×1.3 inches |
|---|
| Product Weight | 288 g (10.16 oz.) |
|---|
| Package Content | - GP1200
- Power Adapter
- Ethernet Cable
- Installation Guide
|
|---|
| Ordering Information | Retail Package Dimension | 304×268×54 mm
11.97×10.55×2.13 inches |
|---|
| Retail Package Weight | EU / US: 681 g (24.02 oz.) |
|---|
| Mechanical | Casing Material | Plastic |
|---|
| Ordering Information | Carton Net Weight | EU / US: 13.6 kg (29.98 lbs) |
|---|
| Carton Gross Weight | EU / US: 15.3 kg (33.73 lbs) |
|---|
| Units per Carton | 20 |
|---|
| Carton Dimension | 55.6×55.5×32.5 cm
21.89×21.85×12.8 inches |
|---|
