AX3000 Gigabit Wi-Fi 6 Mesh Router

AX3000 Gigabit Dual Band Wi-Fi 6 Mesh Router, 802.11ax/ac/a/b/g/n, 2402Mbps at 5GHz + 574Mbps at 2.4GHz, 4 10/100/1000Mbps Ports, 4 x 5dBi fixed antennas, WiFi router/AP/ Repeater/WISP Mode, PPTP/L2TP/OpenVPN/WireGuard, MU-MIMO, Guest network, WPS, DDNS, IPv6, IPTV, WOL, WPA3, TR069/TR098/TR111/TR181, Cudy Mesh, Cudy APP

Manufacturer: Cudy International Limited

Be the first to review this product

Call for pricing

Quantity:

Description

Model Version	WR3000 2.0
CPU	CPU Details	1.2 GHz Dual-Core
Memory/Storage	Flash/ROM	128 MB (1 Gbit) NAND
	DDR/RAM	128 MB (1 Gbit) DDR3
Wireless	5 GHz Wi-Fi Speed	2402Mbps
	2.4 GHz Wi-Fi Speed	574 Mbps
	5 GHz Wi-Fi Streams	2T2R (2×2 MIMO)
	2.4 GHz Wi-Fi Streams	2T2R (2×2 MIMO)
	Wi-Fi Antennas	4× Fixed
	FEM or PA/LNA	5 GHz: 2× Internal 2.4 GHz: 2× Internal
	Beamforming	True
	Range Performance	Max: 200 m (656 ft) Tested in open-space environments with minimal interference. Actual WiFi range may vary depending on layout and wall materials. Refer to the Wall Performance specifications for placement suggestions.
	Wall Performance	Two wooden walls with thickness < 10 cm (4'') One concrete wall with thickness < 20 cm (7'') or two concrete walls with thickness < 10 cm (4'')
Interfaces	Gigabit RJ45 Ports	4
	Ethernet Notes	1× WAN port, the rest are LAN ports
	LED	System Internet WAN LAN 2.4 GHz Wi-Fi 5 GHz Wi-Fi
	Physical Buttons	WPS Button Reset Button
	Power Input	DC Jack
Power	Power Methods	DC
	DC Input	12V 1A
	Power Adapter	Input: 100 ~ 240 V, 50/60 Hz AC Output: 12V 1A DC
	Max Power Consumption (W)	8.8w
	Idle Power Consumption (W)	2.5w
Reliability	Environment	Operating Temperature: 0 ? ~ 40 ? (32 ? ~104 ?) Storage Temperature: -40 ? ~ 70 ? (-40 ? ~ 158 ?) Humidity: 10% ~ 90% non-condensing Storage Humidity: 5% ~ 95% non-condensing
Certifications	FCC, CE
Mechanical	Installation	Desktop Wall-mount
	Dimension	183.3×109×35 mm 7.22×4.29×1.38 inches
	Product Weight	EU: 296 g (10.44 oz.) EU: 252.5 g (8.91 oz.)
Package Content	WR3000 Power Adapter Ethernet Cable Installation Guide
Ordering Information	Retail Package Weight	EU: 614 g (21.66 oz.) EU: 579.0 g (20.42 oz.)
	Retail Package Dimension	240×230×60 mm 9.45×9.06×2.36 inches
	Units per Carton	20
	Carton Dimension	49.5×32.5×48 cm 19.49×12.8×18.9 inches
	Carton Gross Weight	EU: 13.5 kg (29.76 lbs) EU: 12.5 kg (27.56 lbs)
	Carton Net Weight	EU: 12.3 kg (27.12 lbs) EU: 11.6 kg (25.57 lbs)
