| Model Version | M3000 2.0 |
|---|
| CPU | CPU Details | 1.3 GHz Dual-Core, ARM Cortex-A53 |
|---|
| Memory/Storage | Flash/ROM | 128 MB (1 Gbit) NAND |
|---|
| DDR/RAM | 256 MB (2 Gbit) DDR3 |
|---|
| Wireless | 5 GHz Wi-Fi Speed | 2402 Mbps |
|---|
| 2.4 GHz Wi-Fi Speed | 574 Mbps |
|---|
| 5 GHz Wi-Fi Streams | 2T2R (2×2 MIMO) |
|---|
| 2.4 GHz Wi-Fi Streams | 2T2R (2×2 MIMO) |
|---|
| Wi-Fi Antennas | 5× Internal |
|---|
| FEM or PA/LNA | - 5 GHz: 3× Internal
- 2.4 GHz: 2× Internal
|
|---|
| Beamforming | True |
|---|
| Range Performance | Max: 220 m (722 ft)
Tested in open-space environments with minimal interference. Actual WiFi range may vary depending on layout and wall materials. Refer to the Wall Performance specifications for placement suggestions. |
|---|
| Wall Performance | Two wooden walls with thickness < 10 cm (4'')
One concrete wall with thickness < 20 cm (7'') or two concrete walls with thickness < 10 cm (4'') |
|---|
| Indoor Coverage Reference | 2 Pack: 200 m² (2100 sq ft)
3 Pack: 270 m² (2900 sq ft)
Applied to wireless backhaul situation. Place in the center of each floor, with a maximum of three obstacles to each room. |
|---|
| Interfaces | 2.5G RJ45 Ports | 1 |
|---|
| Gigabit RJ45 Ports | 1 |
|---|
| Ethernet Notes | The 2.5G port is the WAN port, the Gigabit port is LAN port |
|---|
| LED | - System
- Speed/Link/ACT of Ethernet Port
|
|---|
| Physical Buttons | |
|---|
| Power Input | DC Jack |
|---|
| Power | Power Methods | DC |
|---|
| DC Input | 12V 1A |
|---|
| Power Adapter | Input: 100 ~ 240 V, 50/60 Hz AC
Output: 12V 1A DC |
|---|
| Max Power Consumption (W) | 11.5W |
|---|
| Idle Power Consumption (W) | 4.2W |
|---|
| Reliability | Environment | - Operating Temperature: 0 ? ~ 40 ? (32 ? ~104 ?)
- Storage Temperature: -40 ? ~ 70 ? (-40 ? ~ 158 ?)
- Humidity: 10% ~ 90% non-condensing
- Storage Humidity: 5% ~ 95% non-condensing
|
|---|
| Certifications | FCC, CE |
|---|
| Mechanical | Installation | Desktop |
|---|
| Dimension | F110×154.5 mm
F4.33×6.08 inches |
|---|
| Product Weight | 360 g (12.7 oz.) |
|---|
| Package Content | - M3000
- Power Adapter
- Ethernet Cable
- Installation Guide
|
|---|
| Ordering Information | Retail Package Weight | - 1-Pack | EU / US: 680 g (23.99 oz.)
- 2-Pack | EU / US: 1370 g (48.33 oz.)
- 3-Pack | EU / US: 1827 g (64.45 oz.)
|
|---|
| Retail Package Dimension | - 1-Pack:
145×130×265 mm
5.71×5.12×10.43 inches - 2-Pack:
330×130×265 mm
12.99×5.12×10.43 inches - 3-Pack:
380×130×265 mm
14.96×5.12×10.43 inches
|
|---|
| Units per Carton | - 1-Pack: 16
- 2-Pack: 8
- 3-Pack: 4
|
|---|
| Carton Dimension | - 1-Pack: 57×56×26 cm
22.44×22.05×10.24 inches - 2-Pack: 55×54.5×35.3 cm
21.65×21.46×13.9 inches - 3-Pack: 53.6×40×28.7 cm
21.1×15.75×11.3 inches
|
|---|
| Carton Gross Weight | - 1-Pack | EU / US: 12.2 kg (26.9 lbs)
- 2-Pack | EU / US: 12.3 kg (27.12 lbs)
- 3-Pack | EU / US: 8.2 kg (18.08 lbs)
|
|---|
| Carton Net Weight | - 1-Pack | EU / US: 10.9 kg (24.03 lbs)
- 2-Pack | EU / US: 11.0 kg (24.25 lbs)
- 3-Pack | EU / US: 7.3 kg (16.09 lbs)
|
|---|
