• High capacity, high density
• High reliability and protection
?STP, RSTP, MSTP
?LACP
?ITU-T G.8032 with fault switching time less than 50ms (the fault detection can be based on physical interface and CFM CC)
?Dual-system and dual-configuration-file redundancy backup
• ISF Stacking (not compatible with L3 features)
?Up to 2 devices
?Liner connection of ring connection
?Uplink connect
• OAM and SLA
?Point-to-point: EEE802.3ah
?End-to-end: hardware IEEE802.1ag to implement 3.3ms CC monitoring
?Rich SLA, ITU-T Y.1731
?MEF CE2.0 certified E-Line, E-LAN, E-TREE and E-Access services
?Hardware BFD
• Various security guarantees
?Various AAA mode such as RADIUS and TACACS+
?IEEE 802.1x authentication
?Port secure MAC and limits on the MAC addresses to stop attacks from illegal users
?Various ACL policies to control packet forwarding flexibly
?DHCPv4/v6 Snooping and Option 82/18/37 to avoid DHCP attacks
?DAI and IP Source Guard based on the DHCP binding table to prevent ARP flooding attacks and IP attacks
?Broadcast storm and loop detection to ensure the stability of the network
?Lightning protection for the power supply and all the Ethernet electric interfaces and protect hardware investment of the customer
• Fine tunable QoS
?Rich scheduling policies such as SP, WRR, or SP + WRR, DRR, or SP+DRR
?Dual-bucket three-color CAR based on the traffic and H-CAR
?Statistics based on traffic
• IPv6 Ready
?IPv6 management
?IPv6 ACL
?DHCPv6 Snooping, RA Snooping and Option18/37 to ensure the network security
?MLD Snooping to ensure the IPv6 multicast monitoring
• Advanced management system
?SNMP, RMON, Telnet, SSH management interface to increase the usability of the device
?Automatic configuration and loading. The administrator can put the configuration file set in advance to the TFTP server for the automatic loading of the switch while it is booting, thus simplifying the management and maintenance
