| Model Version | LT300 2.0 |
|---|
| CPU | CPU Details | 580 MHZ Single-Core, MIPS24KEC |
|---|
| Memory/Storage | Flash/ROM | 8 MB (64 Mbit ) NOR |
|---|
| DDR/RAM | 64 MB (512 Mbit) DDR2 |
|---|
| Cellular | Cellular Standards | 4G Cat. 4 |
|---|
| Cellular Antennas | 2× Fixed |
|---|
| SIM Options | 1× Nano SIM Slot |
|---|
| Available Versions | EU, CN |
|---|
| EU Version Cellular | Suitable Region | Europe, Middle East, Africa |
|---|
| Max DL Speed | 150 Mbps (LTE-FDD), 130 Mbps (LTE-TDD) |
|---|
| Max UL Speed | 50 Mbps (LTE-FDD), 30 Mbps (LTE-TDD) |
|---|
| Advanced | DL 2×2 MIMO |
|---|
| Cellular Bands | LTE-FDD: B1/3/5/7/8/20/28
LTE-TDD: B38/40/41
WCDMA: B1/5/8
|
|---|
| CN Version Cellular | Suitable Region | China, India |
|---|
| Max DL Speed | 150 Mbps (LTE-FDD), 130 Mbps (LTE-TDD) |
|---|
| Max UL Speed | 50 Mbps (LTE-FDD), 30 Mbps (LTE-TDD) |
|---|
| Advanced | DL 2×2 MIMO |
|---|
| Cellular Bands | LTE-FDD: B1/3/5/8
LTE-TDD: B34/38/39/40/41
WCDMA: B1/5/8
GSM: B3/8
|
|---|
| Wireless | 2.4 GHz Wi-Fi Speed | 300 Mbps |
|---|
| 2.4 GHz Wi-Fi Streams | 2T2R (2×2 MIMO) |
|---|
| Wi-Fi Antennas | 2× Internal |
|---|
| FEM or PA/LNA | 2.4 GHz: 2× Internal |
|---|
| Range Performance | Max: 100 m (328 ft)
Tested in open-space environments with minimal interference. Actual WiFi range may vary depending on layout and wall materials. Refer to the Wall Performance specifications for placement suggestions. |
|---|
| Wall Performance | One wooden walls with thickness < 10 cm (4'')
One concrete wall with thickness < 10 cm (4'') |
|---|
| Interfaces | Physical Buttons | |
|---|
| 10/100 Mbps RJ45 Ports | 2 |
|---|
| Ethernet Notes | 1× RJ45 port is WAN/LAN configurable, and the rest are LAN ports |
|---|
| LED | - System
- Cellular Signal Strength
|
|---|
| Power Input | DC Jack |
|---|
| Power | Power Methods | DC |
|---|
| DC Input | 12V 1A |
|---|
| Power Adapter | Input: 100 ~ 240 V, 50/60 Hz AC
Output: 12V 1A DC |
|---|
| Max Power Consumption (W) | 8W |
|---|
| Idle Power Consumption (W) | 3W |
|---|
| Reliability | EMC | ESD: Contact: 4kV; Air: 8kV |
|---|
| Environment | Operating Temperature: 0 ? ~ 40 ? (32 ? ~104 ?)
Storage Temperature: -40 ? ~ 70 ? (-40 ? ~ 158 ?)
Operating Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5% ~ 90% non-condensing |
|---|
| Certifications | FCC, CE |
|---|
| Mechanical | Dimension | 118×80×27.5 mm
4.65×3.15×1.08 inches |
|---|
| Product Weight | 172.2 g (6.07 oz.) |
|---|
| Installation | Desktop |
|---|
| Package Content | - LT300
- Power Adapter
- Ethernet Cable
- Installation Guide
|
|---|
| Ordering Information | Retail Package Weight | EU: 366.5 g (12.93 oz.) |
|---|
| Retail Package Dimension | 176×140.5×56 mm
6.93×5.53×2.2 inches |
|---|
| Units per Carton | 40 |
|---|
| Carton Net Weight | EU: 14.62 kg (32.23 lbs) |
|---|
| Carton Gross Weight | EU: 15.44 kg (34.04 lbs) |
|---|
| Carton Dimension | 60×30×37.5 cm
23.62×11.81×14.76 inches |
|---|
