| Model Version | LT400 2.0 |
|---|
| CPU | CPU Details | 580 MHZ Single-Core, MIPS24KEC |
|---|
| Memory/Storage | Flash/ROM | 8 MB (64 Mbit ) NOR |
|---|
| DDR/RAM | 64 MB (512 Mbit) DDR2 |
|---|
| Cellular | Cellular Standards | 4G Cat. 4 |
|---|
| Cellular Antennas | 2× Fixed |
|---|
| SIM Options | 1× Nano SIM Slot |
|---|
| Available Versions | EU, US, AU, CN |
|---|
| EU Version Cellular | Suitable Region | Europe, Middle East, Africa |
|---|
| Max DL Speed | 150 Mbps (LTE-FDD), 130 Mbps (LTE-TDD) |
|---|
| Max UL Speed | 50 Mbps (LTE-FDD), 30 Mbps (LTE-TDD) |
|---|
| Advanced | DL 2×2 MIMO |
|---|
| Cellular Bands | LTE-FDD: B1/3/5/7/8/20/28
LTE-TDD: B38/40/41
WCDMA: B1/5/8
|
|---|
| US Version Cellular | Suitable Region | United States, Canada |
|---|
| Max DL Speed | 150 Mbps |
|---|
| Max UL Speed | 50 Mbps |
|---|
| Advanced | DL 2×2 MIMO |
|---|
| Cellular Bands | LTE-FDD: B2/4/5/12/13/14/66/71
WCDMA: B2/4/5
|
|---|
| AU Version Cellular | Suitable Region | Latin America, Australia, New Zealand |
|---|
| Max DL Speed | 150 Mbps (LTE-FDD), 130 Mbps (LTE-TDD) |
|---|
| Max UL Speed | 50 Mbps (LTE-FDD), 30 Mbps (LTE-TDD) |
|---|
| Advanced | DL 2×2 MIMO |
|---|
| Cellular Bands | LTE-FDD: B1/2/3/4/5/7/8/28/66
LTE-TDD: B40
WCDMA: B1/2/4/5/8
GSM: B2/3/5/8
|
|---|
| CN Version Cellular | Suitable Region | China, India |
|---|
| Max DL Speed | 150 Mbps (LTE-FDD), 130 Mbps (LTE-TDD) |
|---|
| Max UL Speed | 50 Mbps (LTE-FDD), 30 Mbps (LTE-TDD) |
|---|
| Advanced | DL 2×2 MIMO |
|---|
| Cellular Bands | LTE-FDD: B1/3/5/8
LTE-TDD: B34/38/39/40/41
WCDMA: B1/5/8
GSM: B3/8
|
|---|
| Wireless | 2.4 GHz Wi-Fi Speed | 300 Mbps |
|---|
| 2.4 GHz Wi-Fi Streams | 2T2R (2×2 MIMO) |
|---|
| Wi-Fi Antennas | 2× Fixed |
|---|
| Beamforming | True |
|---|
| FEM or PA/LNA | 2.4 GHz: 2× Internal |
|---|
| Range Performance | Max: 130 m (427 ft)
Tested in open-space environments with minimal interference. Actual WiFi range may vary depending on layout and wall materials. Refer to the Wall Performance specifications for placement suggestions. |
|---|
| Wall Performance | One wooden walls with thickness < 10 cm (4'')
One concrete wall with thickness < 10 cm (4'') |
|---|
| Interfaces | Physical Buttons | Reset Button |
|---|
| 10/100 Mbps RJ45 Ports | 4 |
|---|
| Ethernet Notes | 1× RJ45 port is WAN/LAN configurable, and the rest are LAN ports |
|---|
| LED | - Cellular
- Wi-Fi
- LAN
- WAN/LAN
- Internet
- Power
|
|---|
| Power Input | DC Jack |
|---|
| Power | Power Methods | DC |
|---|
| DC Input | 12V 1A |
|---|
| Power Adapter | Input: 100 ~ 240 V, 50/60 Hz AC
Output: 12V 1A DC |
|---|
| Reliability | EMC | ESD: Contact: 4kV; Air: 8kV |
|---|
| Environment | Operating Temperature: 0 ? ~ 40 ? (32 ? ~104 ?)
Storage Temperature: -40 ? ~ 70 ? (-40 ? ~ 158 ?)
Operating Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5% ~ 90% non-condensing |
|---|
| Certifications | FCC, CE |
|---|
| Mechanical | Dimension | 229×123×32.7 mm
9.02×4.84×1.29 inches |
|---|
| Product Weight | - EU: 276 g (9.74 oz.)
- ZH: 278.6 g (9.83 oz.)
|
|---|
| Installation | |
|---|
| Package Content | - LT400
- Power Adapter
- Ethernet Cable
- Installation Guide
|
|---|
| Ordering Information | Retail Package Weight | - AU: 758 g (26.74 oz.)
- EU: 775 g (27.34 oz.)
- UK: 805 g (28.4 oz.)
- US: 774 g (27.3 oz.)
- ZH: 701.8 g (24.76 oz.)
|
|---|
| Carton Net Weight | - AU: 7.6 kg (16.76 lbs)
- EU: 7.8 kg (17.2 lbs)
- UK: 8.0 kg (17.64 lbs)
- US: 7.8 kg (17.2 lbs)
- ZH: 7.0 kg (15.43 lbs)
|
|---|
| Carton Gross Weight | - AU: 8.25 kg (18.19 lbs)
- EU: 8.85 kg (19.51 lbs)
- UK: 9.0 kg (19.84 lbs)
- US: 8.4 kg (18.52 lbs)
- ZH: 8.1 kg (17.86 lbs)
|
|---|
