Dimensions
442 x 325 x 87 mm(17.4 x 12.8 x 3.4")
Managed Cameras
(70) HD(35) 2K(24) 4K
Storage Capacity
(7) 3.5" drive bays
Networking Interface
(1) 10G SFP+ port(1) GbE RJ45 port
Form Factor
Rack mount (2U)
Hard Drive Capacity
(7) 2.5/3.5" HDD / SSD support
Max. Power Budget for Drives
135W
Max. Power Consumption
160W
Power Method
(1) Universal AC input, 100—240V AC, 3A Max., 50/60 Hz(1) USP-RPS DC input, 11.5V DC, 13.91A
Power Supply
AC/DC, internal, 200W
Processor
Quad ARM® Cortex®-A57 cores at 1.7GHz
Weight
Without mounting brackets: 9.2 kg (20.3 lb)With mounting brackets: 9.5 kg (20.8 lb)
Enclosure Material
SGCC steel
Ambient Operating Temperature
-5 to 40° C (23 to 104° F)
Ambient Operating Humidity
5 to 95% noncondensing
Certifications
CE, FCC, IC, Anatel: 06697-21-08356
