Hardware |
Uplink Port | 4*1G (SFP)/10G (SFP+) + 4*10G (SFP+)/25G (SFP28) 2*40G (QSFP+)/100G (QSFP28) + 2*1G (SFP)/10G (SFP+) |
PON Port | Quantity | 8*GPON/16*GPON/8*XG(S)PON |
Physical interface | SFP slot |
Interface type | GPON: ITU-TG.984.2 Class B+/Class C+ |
Max splitting ratio | GPON: 1:128 |
Management Port | 1 100/1000BASE-Tx out-band Ethernet port 1 CONSOLE local management port |
PON Port attribute | Transmission distance | 20KM |
Port rate | GPON: Downstream: 2.5Gbps Upstream: 1.25Gbps |
Wavelength | Forwarding: 1490nm Receiving: 1310nm |
Interface type | SC/UPC |
Fiber type | 9/125µm SMF (Single Mode Fiber) |
Light transmission power | Class B+: +1.5 ~ +5dBm Class C+: +3 ~ +7dBm |
Receiving sensitivity | Class B+: -28dBm Class C+: -30dBm |
Saturation power | Class B+: -8dBm Class C+: -12dBm |
Backplane Bandwidth | 400G |
