Dimensions
442 x 400 x 44 mm(17.4 x 15.7 x 1.7")
1 GbE RJ45
48 (40 PoE+; 8 PoE++)(1G/100M/10M)
Max. PoE Output
Up to PoE++
Total PoE Availability
600W
Redundancy
DC Power Backup
Form Factor
Rack mount (1U)
Switching Capacity
176 Gbps
Total Non-Blocking Throughput
88 Gbps
MAC Address Table Size
16,000
DHCP Server (Local Networks)
Yes
Inter-VLAN Routing (Local Networks)
Yes
Static Routing (Local Networks)
Yes
Pro AV Profiles (Play, Dante, Q-SYS, NDI, SDVoE, Shure, AES67, Crestron)
Yes
Advanced IGMP Configuration (Querier, Fast Leave, Router Port)
Yes
MAC-Based ACLs & Device Isolation
Yes
DHCP Snooping & Guarding
Yes
Multicast & Broadcast Rate Limiting
Yes
IP-Based ACLs & Network Isolation
Yes
MAC-Based Port Restriction
Yes
Max. PoE Wattage per Port by PSE
Max. Power Consumption
60W (Excluding PoE Output)660W (Including PoE Output)
Power Method
(1) Universal input, 100—240V AC, 50/60 Hz(1) USP RPS DC input
Power Input Method
AC input
Power Supply
AC/DC, internal, 660W
Supported Voltage Range
100—240V AC
Heat Dissipation
204.7 BTU/hr (Excluding PoE Output)
Weight
Without mounting brackets: 6.2 kg (13.7 lb)With mounting brackets: 6.3 kg (13.9 lb)
Enclosure Material
SGCC steel
Supported Rack Depth
400~1200 mm(15.7-47.2")
LCM Display
1.3" touchscreen
ESD Protection
Air: ± 16kV, contact: ± 12kV
Ambient Operating Temperature
-5 to 40° C (23 to 104° F)
Ambient Operating Humidity
10 to 90% noncondensing
Certifications
CE, FCC, IC, Anatel: 13790-20-08356
UniFi Network
Version 5.10.5 and later<
