Audio Features > Yealink HD voice > Full-duplex hands-free speakerphone with AEC > Codec: G.722 (Wideband) , G.711 (A/µ), G.723.1, G.729AB, G.726, GSM, iLBC > DTMF: In-band, Out-of-band(RFC 2833) and SIP INFO > DTMF: In-band, Out-of-band(RFC 2833) and SIP INFO
> VAD, CNG, AEC, PLC, AJB, AGC
Directory > Contacts synchronize with client > View Microsoft Skype for Business/Lync contacts and their current presence status > Favorite contacts > Support search Active Directory contacts > Intelligent search method > Call history: placed/received/missed/forwarded
Signing into Microsoft Skype for Business/Lync
> Sign in: PIN Authentication/User credentials > Signing in via BToE > Signing in via phone web interface > Auto root certificate fetch
Phone features > Presence status synchronize with client > Reset presence status > Call hold, mute, DND > Call waiting, Redial > Branch office support > Call forward, call transfer, call park > Local 3-way conferencing > E911, Federation, Response group > Ring tone selection/import/delete > Dial plan > Private line > Voice mail, Message waiting indicator (MWI) > Volume adjustment
BToE features > Click to call/Click to answer > Audio device switch from IP Phone to PC/windows PAD > Pair phone with IP
Interface > 2xRJ45 10/100M Ethernet ports > Power over Ethernet (IEEE 802.3af ) , class 2 > 1 xRJ9 (4P4C) handset port > 1 xRJ9 (4P4C) headset port
Display and indicator > 132x64-pixel graphical LCD with backlight > One-color (green) illuminated LEDs for line status information > Intuitive user interface with icons and soft keys > LED for call and message waiting indication > National language selection > Caller ID with name, number > Presence status control : available, busy, DND, be right back, off work, appear away
Network and security
> SIP v1 (RFC2543), v2 (RFC3261 ) > LLDP-MED VLAN assignment > IPv6 > Proxy mode and peer-to-peer SIP link mode > IP Assignment: Static/DHCP/PPPoE > DNS Assignment: Static/DHCP > HTTP/HTTPS web server > Time and date synchronization using SNTP > UDP/TCP/DNS-SRV(RFC 3263) > QoS: 802.1p/Q tagging (VLAN), Layer 3 ToS, DSCP > SRTP for voice > Transport Layer Security (TLS) > HTTPS certificate manager > Digest authentication using MD5/MD5-sess > IEEE802.1 X
Management > Configuration: browser/phone/Auto provisioning > Support of in-band provisioning from Microsoft Skype for Business/Lync Server > Single identity (active directory) > Media Bypass > Firewall Traversal > Reset to factory, reboot > Package tracing export, system log
Network and Security > Wall mountable > External universal AC adapter (optional): AC 100~240V input and DC 5V/1.2A output > Power consumption (PSU): 1.4-2.0W > Power consumption (PoE): 2.1-2.9W > Dimension(W*D*H*T): 209mm*188mm*150mm*41mm > Operating humidity: 10~95% > Operating temperature: -10~50°C
Package Features > Qty/CTN: 10 PCS > N.W/CTN: 11.7kg > G.W/CTN: 12.6kg > Giftbox size: 215mm*200mm*118mm > Carton Meas: 615mm*436mm*208mm |
