Dimensions
442 x 120 x 43.7 mm(17.4 x 4.7 x 1.7")
Form Factor
Rack mount (1U)
Switching Capacity
160 Gbps
Total Non-Blocking Throughput
80 Gbps
MAC Address Table Size
16,000
Advanced IGMP Configuration (Querier, Fast Leave, Router Port)
Yes
MAC-Based ACLs & Device Isolation
Yes
DHCP Snooping & Guarding
Yes
Multicast & Broadcast Rate Limiting
Yes
IP-Based ACLs & Network Isolation
Yes
MAC-Based Port Restriction
Yes
Max. Power Consumption
36W (Including SFP modules)
Power Method
Universal input, 100—240V AC, 50/60 Hz
Power Input Method
AC input
Power Supply
AC/DC, internal, 36W
Supported Voltage Range
100—240V AC
Heat Dissipation
102 BTU/hr
Weight
Without mounting brackets: 2.6 kg (5.8 lb)With mounting brackets: 2.7 kg (6 lb)
Enclosure Material
SGCC steel
Supported Rack Depth
400~1200 mm(15.7-47.2")
LCM Display
1.3" touchscreen
ESD Protection
Air: ± 16kV, contact: ± 12kV
Ambient Operating Temperature
-5 to 40° C (23 to 104° F)
Ambient Operating Humidity
10 to 90% noncondensing
Certifications
CE, FCC, IC, Anatel: 04456-21-08356
UniFi Network
Version 5.14.12 and later
