Basic |
Layer | Layer 2 |
Switching Capacity | 20 Gbps |
Packet Forwarding Rate | 14.88 Mpps |
Description of Function Slots | Port 1-8: 8 × RJ-45 10/100/1000 Mbps (PoE)
Port 9-10: 2 × RJ-45 10/100/1000 Mbps (uplink) |
Operating Temperature | –10 °C to +55 °C (+14 °F to +131 °F) |
Operating Humidity | 10%–90% (RH), non-condensing |
Storage Temperature | –40 °C to +75 °C (–40 °F to +167 °F) |
Storage Humidity | 5%–95% (RH), non-condensing |
Power Supply | External Power Adapter (53 V, 1.22 A) |
Power Consumption | Idling: 4 W
Full load: 63 W |
Statics Protection | Air discharge: 8 kV
Contact discharge: 6 kV |
Lightning Protection | Common mode: 6 kV
Differential mode: 1 kV |
Net Weight | 0.36 kg (0.79 lb) |
Gross Weight | 0.95 kg (2.09 lb) |
Product Dimensions | 184.6 mm × 103.3 mm × 27 mm (7.27" × 4.07" × 1.06") (L × W × H) |
Packaging Dimensions | 252 mm × 137 mm × 113 mm (9.92" × 5.39" × 4.45") (L × W × H) |
Casing Material | Sheet metal |
Installation | Desktop mount; wall mount |
Certifications | CE |
PoE |
PoE | Yes |
PoE Power | Port 2-8=30 W, port 1=60 W, total=60 W |
PoE Protocol | IEEE 802.3af; IEEE 802.3at; Hi-PoE |
PoE Power Consumption Management | PoE power consumption management; PoE power on/off; turns off PoE if overload is detected |
PoE Pin Assignment | 1,2, (V+), 3 ,6, (V-) |
Long Distance PoE Transmission | Yes |
Hardware |
DIP Switch | Managed Mode: On by default for both local web and cloud management. Off for Unmanaged Mode.
PoE Watchdog: Monitors ports 1-8 and auto-restarts the PoE port when there is no traffic for 2 min. (Only works when Managed Mode is Off)
Extend Mode: Ports 1-8; transmission distance up to 250 meters at 10 Mbps. (Only works when Managed Mode is Off) |
Reset Button | 1 |
Performance |
MTBF | 2,482,955 hours |
Packet Buffer Size | 4 Mbit |
Jumbo Frame | 15360 Byte |
MAC Table Size | 8K |
Communication Standard | IEEE 802.3; IEEE 802.3u; IEEE 802.3x; IEEE 802.3ab; IEEE 802.3az; IEEE 802.3ad |
VLAN Number | 32 |
Feature |
Ethernet Loop Protection | STP; RSTP |
VLAN Function | IEEE 802.1Q VLAN |
Link Aggregation | Static Aggregation |
Port Feature | IEEE 802.3x Flow Control
Unknown Unicast Suppression
Multicast Storm Control
Broadcast Storm Control
MAC+Port Binding
Loop Prevention |
Mirror | Local Port Mirroring
N:1 Mirroring |
Reliability | LLDP |
DHCP Function | DHCP Client |
Security | Port Isolation |
Equipment Management | Web Management
Cloud Management
Logs
Fault Alarm |
General |
Packing List | 1 × User Manual
1 × Legal and Regulatory Information
1 × Power Cord
1 × Power Adapter |
